BW Brass cable glands are per BS 6121 Part 1:1989 and suitable for single wire armoured plastic or rubber sheathed cabels. These glands provide mechanical cable retention and electrical continuity via armour wire termination. The use of these glads is recommended in dry, indoor situations, Shrouds may be used for ingress protection.
| GLAND SIZE | ENTRY THREAD | CABLE ACCEPTANCE DETAILS | ACROSS FLAT | ACROSS CORNER | |||
|---|---|---|---|---|---|---|---|
|
DIA. C |
LENGTH MINIMUM E |
DIA MAX. A |
DIA MAX. B |
ARMOUR DIAMETER D |
|||
| 20S | 20 | 9 | 11.60 | 16.00 | 0.9/1.25 | 21.50 | 24.50 |
| 20L | 20 | 9 | 14.00 | 20.00 | 0.9/1.25 | 24.20 | 27.30 |
| 25S | 25 | 9 | 19.00 | 24.00 | 1.25/1.60 | 30.00 | 33.60 |
| 25L | 25 | 10 | 20.00 | 27.00 | 1.25/1.60 | 30.00 | 34.40 |
| 32S | 32 | 10 | 24.00 | 30.50 | 1.60/2.00 | 36.50 | 40.00 |
| 32L | 32 | 10 | 26.20 | 33.00 | 1.60/2.00 | 36.50 | 42.30 |
| 40S | 40 | 11 | 30.00 | 37.00 | 1.60/2.00 | 44.50 | 50.00 |
| 40L | 40 | 11 | 32.50 | 41.00 | 1.60/2.00 | 46.50 | 52.00 |
| 50S | 50 | 13 | 40.00 | 47.50 | 2.00/2.50 | 55.00 | 62.00 |
| 50L | 50 | 13 | 44.00 | 52.60 | 2.00/2.50 | 59.00 | 66.00 |
| 63S | 63 | 14 | 51.00 | 60.00 | 2.50 | 69.00 | 76.00 |
| 63L | 63 | 14 | 55.00 | 66.00 | 2.50 | 73.00 | 82.00 |
| 75S | 75 | 15 | 62.00 | 72.00 | 2.50 | 83.00 | 94.00 |
| 75L | 75 | 15 | 67.00 | 78.00 | 2.50 | 86.30 | 98.00 |
| 90S | 90 | 20 | 74.00 | 84.00 | 2.50/3.15 | 94.00 | 104.00 |
| 90L | 90 | 20 | 79.00 | 90.00 | 2.50/3.15 | 105.00 | 118.00 |
