E1W type brass cable glands are as per BS 612 Part I:1989 suitable for indoor as well as outdoor applications. These glands are suitable for all types of SWA cable, providing environmental seal on both the cable inner and electrial continuity via armour wire termination.
| GLAND SIZE | ENTRY THREAD | CABLE ACCEPTANCE DETAIL | ACROSS FLAT | ACROSS CORNER | |||
|---|---|---|---|---|---|---|---|
| DIA. C | LENGTH MINIMUM E | DIA MAX. A | DIA MAX. B | ARMOUR DIAMETER D | |||
| 20S | 20 | 10 | 8.00-11.80 | 12.90-17.20 | 0.90/1.25 | 24.00 | 27.00 |
| 20L | 20 | 10 | 11.00-14.00 | 15.50-20.80 | 0.90/1.25 | 27.70 | 31.00 |
| 25S | 25 | 10 | 12.00-17.00 | 17.50-24.00 | 1.25/1.60 | 31.50 | 35.00 |
| 25L | 25 | 10 | 13.00-20.30 | 24.00-27.20 | 1.25/1.60 | 35.00 | 39.00 |
| 32S | 32 | 10 | 17.00-24.00 | 25.00-31.00 | 1.60/2.00 | 43.00 | 47.50 |
| 32L | 32 | 10 | 19.00-26.20 | 26.70-34.00 | 1.60/2.00 | 43.00 | 47.50 |
| 40S | 40 | 15 | 23.00-30.00 | 31.00-38.50 | 1.60/2.00 | 51.50 | 57.00 |
| 40L | 40 | 15 | 25.00-32.20 | 33.00-40.50 | 1.60/2.00 | 51.50 | 57.00 |
| 50S | 50 | 15 | 31.50-38.20 | 39.40-46.80 | 2.00/2.50 | 58.50 | 65.00 |
| 50L | 50 | 15 | 36.50-44.00 | 45.70-53.20 | 2.00/2.50 | 66.00 | 73.00 |
| 63S | 63 | 15 | 42.50-50.00 | 52.10-59.00 | 2.50 | 72.00 | 80.00 |
| 63L | 63 | 15 | 49.10-56.00 | 58.40-66.00 | 2.50 | 80.00 | 89.00 |
| 75S | 75 | 17 | 54.50-62.00 | 64.80-72.00 | 2.50 | 86.50 | 97.00 |
| 75L | 75 | 17 | 60.50-68.00 | 71.10-78.00 | 2.50 | 94.00 | 105.00 |
| 90L | 90 | 20 | 66.00-79.00 | 77.00-90.00 | 2.50/3.15 | 106.00 | 118.00 |
