Flange Type Cable Glands are made out of brass castings and are machined accurately to the required sizes. These glands are suitable for armoured calbes and are called mechanical glands hence suitable for outdoor applications.
The gland comprises of brass body (flange type oval shape) and plate clamped with galavanised mild steel studs and nuts for clamping the armour. Taered cone and nut are provided for termination of cable. The cone and body taper is designed for giving a firm grip to the armour of the cable.
| CODE NO. | E(mm) |
MAX DIA OF CABLE |
UNDER ARMOUR DIA |
L | ACCEPTANCE DIA | |
|---|---|---|---|---|---|---|
| MIN | MAX | |||||
| FL 5 | 15.0 | 16.5 | 10.0 | 13.0 | 12.0 | 16.5 |
| FL 4 | 19.0 | 19.0 | 13.5 | 13.0 | 15.0 | 19.0 |
| FL 3 | 19.5 | 20.5 | 13.0 | 13.0 | 18.5 | 20.5 |
| FL 2 | 25.0 | 24.5 | 19.0 | 16.5 | 20.5 | 24.5 |
| FL 1 | 31.0 | 30.0 | 25.5 | 15.5 | 24.0 | 30.0 |
| FL 11 | 31.0 | 34.0 | 28.0 | 15.0 | 29.5 | 34.0 |
| FL 0 | 37.5 | 35.0 | 29.5 | 21.0 | 32.5 | 35.0 |
| FL 00 | 37.5 | 38.0 | 29.5 | 20.0 | 34.5 | 38.0 |
| FL 38 | 42.0 | 42.0 | 34.5 | 21.5 | 37.0 | 42.0 |
| FL 001 | 49.0 | 44.0 | 41.0 | 20.5 | 40.5 | 44.0 |
| FL 002 | 53.5 | 52.0 | 46.0 | 21.5 | 43.5 | 52.0 |
| FL 003 | 60.0 | 58.0 | 52.0 | 23.0 | 51.0 | 58.0 |
| FL 0033 | 65.0 | 67.0 | 56.0 | 25.5 | 56.5 | 67.0 |
| FL 004 | 75.0 | 76.0 | 65.2 | 22.5 | 66.0 | 76.0 |
| FL 005 | 99.0 | 83.0 | 88.0 | 22.5 | 75.0 | 83.0 |
